micro serial cable
micro usb to db9 cable
db9 to micro usb l shape
cp2102 chip

CP2102+ZT213 chip
USB2.0 RS232 to DB9 full pinout
DB9 male pinout:1-DCD, 2-RXD, 3-TXD, 4-DTR, 5-GND,6-DSR,7-RTS,8-CTS,9-RI
USB RS232 COM port converter cable
USB serial adapter cable
usb-COM232 adapter cable
USB RS232 DB9 male cable
USB specification 2.0 compliant, full speed(12Mbps)
USB suspend states supported via SUSPEND pins
All handshaking and modem interface signals
Data formates supported: Data bit: 5, 6, 7, and 8, Stope bits: 1, 1.5. and 2. Parity: odd, even, mark, space, no parity
Baud rates: 300bps to 1 Mbits
576 byte receive buffer; 640 byte transmit uffer
Hardware or X-On/X-Off handshaking supported
Even character support
Line break transmission
RS232 standard signal
1.0mtr in length in stock
24/28AWG with braid for shielding, OD=4.0mm
Update serial PLC, modem to usb, bar coder reader, scaner, etc
Compatible PC serial power level
Support Windows 7/Win8, Win 8.1/10/XP/9X/2000, Linux,Mac,etc
With DB9 full pinout:
DB9 male full
About CP2102
Single-Chip USB to UART Data Transfer
-Integrated USB transceiver; no external resistors required
-Integrated clock; no external crystal required
-Internal 1024-byte programmable ROM for vendor ID, product ID, serial number, power descriptor, release number, and product description strings
- EEPROM (CP2102)
- EPROM (One-time programmable) (CP2109)
-On-chip power-on reset circuit
-On-chip voltage regulator
- 3.3 V output (CP2102)
- 3.45 V output (CP2109)
-100% pin and software compatible with CP2101

USB Function Controller
-USB Specification 2.0 compliant; full-speed (12 Mbps)
-USB suspend states supported via SUSPEND pins

Asynchronous Serial Data BUS (UART)
-All handshaking and modem interface signals
-Data formats supported:
-   Data bits: 5, 6, 7, and 8
-   Stop bits: 1, 1.5, and 2
-   Parity: odd, even, mark, space, no parity
-Baud rates: 300 bps to 1 Mbps
-576 Byte receive buffer; 640 byte transmit buffer
-Hardware or X-On/X-Off handshaking supported
-Event character support
-Line break transmission

Virtual COM Port Device Drivers
-Works with existing COM port PC Applications
-Royalty-free distribution license
-Windows 10/8/7/Vista/Server 2003/XP/2000
-Mac OS-X/OS-9
-Linux

USBXpress? Direct Driver Support
-Royalty-Free Distribution License
-Windows 7/Vista/XP/Server 2003/2000
-Windows CE

Example Applications
-Upgrade of RS-232 legacy devices to USB
-Cellular phone USB interface cable
-USB interface cable
-USB to RS-232 serial adapter
Supply Voltage
-Self-powered: 3.0 to 3.6 V
-USB bus powered: 4.0 to 5.25 V
CP210x USB to UART Bridge VCP Drivers
The CP210x USB to UART Bridge Virtual COM Port (VCP) drivers are required for device operation as a Virtual COM Port to facilitate host communication with CP210x products. These devices can also interface to a host using the direct access driver. These drivers are static examples detailed in application note 197: The Serial Communications Guide for the CP210x, download an example below:
AN197: The Serial Communications Guide for the CP210x
Download Software

The CP210x Manufacturing DLL and Runtime DLL have been updated and must be used with v6.0 and later of the CP210x Windows VCP Driver. Application Note Software downloads affected are AN144SW.zip, AN205SW.zip and AN223SW.zip. If you are using a 5.x driver and need support you can download archived Application Note Software.
Windows 7/8/8.1/10 (v6.7.3) ?
Windows XP/Server 2003/Vista/7/8/8.1 (v6.7) ?
Windows 2K (v6.3a) ?
WinCE ?
Macintosh OSX (v4) ?
Linux ?
Android ?
Download for Windows 7/8/8.1/10 (v6.7.3)

Platform Software Release Notes
Windows 7/8/8.1/10 Download VCP (5.3 MB) (Default) Download VCP Revision History
Windows 7/8/8.1/10 Download VCP with Serial Enumeration (5.3 MB)
Learn More ? Download VCP Revision History



Download for Windows XP/Server 2003/Vista/7/8/8.1 (v6.7)

Platform Software Release Notes
Windows XP/Server 2003/Vista/7/8/8.1 Download VCP (3.66 MB) Download VCP Revision History



Download for Windows 2K (v6.3a)

Platform Software Release Notes
Windows 2K Download VCP (4.79 MB) Download Win2K VCP Revision History



Download for WinCE

Platform Software Release Notes
WinCE 6.0 (2.1) Download VCP (276 KB) Download WinCE 6.0 Revision History
WinCE 5.0 (2.1) Download VCP (271 KB) Download WinCE 5.0 Revision History



Download for Macintosh OSX (v4)

Platform Software Release Notes
Mac OSX Download VCP (832 KB) Download Mac VCP Revision History



Download for Linux

Platform Software Release Notes
 Linux 3.x.x Download VCP (10.0 KB) Download Linux 3.x.x VCP Revision History
 Linux 2.6.x Download VCP (10.2 KB) Download Linux 2.6.x VCP Revision History
*Note: The Linux 3.x.x version of the driver is maintained in the current Linux 3.x.x tree at www.kernel.org.


Download for Android

Platform Application Note
 Android 4.2 AN809: Integrating the CP210x Virtual COM Port Driver into the Android Platform
